Jul 162017


Every month, patrons of the Aerospace Projects Review Patreon campaign are rewarded with a bundle of documents and diagrams, items of interest and importance to aerospace history. If you sign up, you get the monthly rewards going forwards; the “back issues” catalog lets patrons aid the APR cause by picking up items from before they signed on. The catalog, available to all patrons at the APR Patreon, has been updated to include everything from the beginning of the project back in 2014 on up to February, 2017.

Below are the items from 2016 (and the first two months of 2017):



If you are interested in any of these and in helping to fund the mission of Aerospace Projects Review, drop by the APR Patreon page and sign up. For only a few bucks a month you can help fund the procurement, scanning and dissemination of interesting aerospace documentation that might otherwise vanish from the public.

 Posted by at 12:49 am
Apr 152017


Now available: two new US Aerospace Projects issues:

US Transport Projects #07

US Transport Projects #07 is now available (see HERE for the entire series). Issue #07 includes:

  • Lockheed L-279-9: an early SST
  • Convair HST – Phase II Variable Sweep Configuration: A mid-1960’s hypersonic transport
  • Lockheed CL-1373: a short-haul turboprop liner
  • Boeing Model 702-134(4): a large nuclear-powered logistics hauler
  • McDonnell-Douglas Swept Wing Spanloader: a heavy cargo carrier
  • Lockheed Hybrid Wing Body: a current design for an efficient military transport
  • NASA Cut-Down 747 SCA: a 1973 idea for a Shuttle Carrier Aircraft
  • Rockwell Boost Glide Transport: An early 1970’s rocket transport



USTP #07 can be downloaded as a PDF file for only $4:

——–


Also available, the first in a new series:

US Recon and Research Projects #01

US Recon & Research Projects #01 is now available (see HERE for the entire series). Issue #01 includes:

  • General Dynamics “FISH”: 1958 concept for Mach 4 parasite
  • NACA-Langley X-Tail X-15: early hypersonic rocket plane concept
  • “Jake’s Jeep”: WWII-era motorjet design
  • Lockheed “Archangel”: The first step on the road to the SR-71
  • Boeing Model 853-21 “Quiet Bird”: A 1961 stealth platform
  • Northrop Tacit Blue: Operational version of the early stealth experiment
  • Convair Pilotless Airplane I-40 Inhabited: WWII-era design of a manned test for a flying bomb
  • Lockheed CL-278-1-1: a proto-U-2



USRP #01 can be downloaded as a PDF file for only $4:

——–

——

 Posted by at 11:43 am
Apr 122017


So very, very close on the next two US Aerospace Projects issues. I’m only lacking cover “art”and have to deal with a bit of “dead air” in the middle of US Transport Projects #7. Usually I can shuffle things around well enough to not have this sort of thing, but this time it just hasn’t worked out. I suppose it doesn’t really matter all that much, but it does look kinda lazy like that.

It’s been about a year since I released the last USxP issue. That last issue was the first time where I used vector diagrams embedded within the issue, rather than raster images; getting the diagrams from AutoCAD into Word was a bit of a chore back then. And in the intervening months… I forgot how I did it. So I had to figure it out again, and the process is different. I have to walk the AutoCAD diagram through Rhino 3D and save as a WMF and blah, blah, blah; end result is it works just fine. I’ve done some further refinement… the main outlines are set at 0.25 mm width and the ends of the lines have been reset to rounded and mitered, so sharp corners now look more like sharp corners.

Hoping to have these two out in a day or two. The other three will be rather longer.



 Posted by at 6:57 pm
Apr 022017


I’m essentially done with the drafting portion of the exercise. Now to finish the writing. I had planned on releasing ll five at once, but due to external factors I’ll almost certainly have to split this up. So… which ones do people want more? The publications forthcoming are Fighters, Bombers, Transports, Launchers and Recon & Research. Comment below…

 Posted by at 11:05 pm
Mar 102017


Coming soonish: the return of USXP publications. Five are under current development and are mostly done. There is a new title in the bunch… USRP. Strictly speaking it should probably be USR&RP… United States Research and Recon Projects. Perhaps Recon and Research aren’t necessarily the most obvious categories to link together into a single title, but apart from the vitally important alliteration, there is this important fact: compared to, say, Bombers, there aren’t that many Recon and Research projects out there.

If there are specific proposals, or general categories you’d like to see in future publications, feel free to comment below.

 Posted by at 10:41 am
Oct 302016


I’ve been running the Aerospace Projects Review Patreon project for a bit over two years now. Every month, Patrons get rewarded with sets of aerospace history stuff… currently, one large-format diagram or piece of artwork, three documents and, depending on level of patronage, an all-new CAD diagram of an aerospace subject of interest. More than two dozen such packages have been put together so far and distributed. Given that you can get in on this for as little as $1.50 a month (for 125-dpi scans… $4/month for full-rez 300 dpi scans) and you get at least four items, that’s a pretty good bargain compared to the individual aerospace drawings and documents.

Patrons who signed up after the process got underway can now get “back issues” of the previously released rewards packages. A catalog of more than the first years worth has just been posted; each month will see an updated catalog posted for Patrons to order from. So if you are interested, check out the APR Patreon page to see how to sign up; if you are already a patron, check out the catalog here.

 Posted by at 3:41 pm
Jun 252016


A heavily illustrated USAF brochure on turbine engine technology included, among a vast number of little photos of engines and aircraft, a few illustrations that might be of interest.

Several futuristic concepts here, several old ones. Of particular interest is the “Supersonic Multirole Fighter,” which looks like a cross between the old Lockheed Hopeless Diamond concept and the Northrop XST design… tailless with an inlet on top, with features reminiscent of the F-117, but blended rather than faceted.

aeroclipart2



Of these “Emerging Concept Needs,” several are distinctly old. The middle row of three designs are all 20+ year-old concepts.

aeroclipart3

aeroclipart4

 Posted by at 6:08 pm
May 302016


I’ve recently figured out how to get reliably good-quality vector graphic PDF files from my AutoCAD diagrams.These differ from standard “raster” graphics like GIFs and JPGs in that they are composed of scalable lines rather than pixels; this means that they can be printed off at many scales and they’ll retain clarity.

I think a lot of the diagrams would look quite good printed in large format; I’ve previously mentioned that I’m working on a few diagrams specifically for printing off on large format (24X36) mylar, but I’ve others that I think would also look good scaled for 18X24. I’m making these first seven diagrams available, formatted and scaled for 18X24. They can be viewed on screen, printed on a standard printer or printed by a large format printer all with equal clarity.

If this idea appeals, be sure to tell your friends, family, foes, anyone you think might be interested. Also be sure to comment if there are any diagrams I’ve previously created for APR, USXP or elsewhere that you’d like to see in this format. Some of them would be best as multi-sheet diagrams. Suggestions on how to improve also appreciated.

CAD007

CAD 007: Northrop Low Altitude Penetrator

A 1/72 diagram of a 1979 design for a B-2 alternate configuration

Download for $3

———————————

CAD006

CAD 006

A 1/96 scale diagram of the 1979 Rockwell D645-4a spanloader bomber.

Download for $3

———————————

CAD005

CAD 005

A 1/144 scale diagram of the Manned Spacecraft Center MSC Orbiter 020, a 1972 Space Shuttle concept with a single 260″ solid rocket booster.

Download for $3

———————————

CAD004

CAD 004

A 1/350 scale diagram of the 1971 Boeing Resource Air Carrier (AKA RC-1, AKA “Brute Lifter”) designed as a flying oil tanker for the arctic.

Download for $3

———————————

CAD003

CAD 003

A 1/72 scale diagram of the Martin-Marietta “Zenith Star” experimental space-based laser for the Strategic Defense Initiative.

Download for $3

———————————

CAD002

CAD 002

A 1/24 diagram of the Lockheed “Harvey,” the initial concept for a low radar cross section strike platform that eventually became the F-117.

Download for $3

———————————

CAD001

CAD 001

A 1/32 diagram of the North American Rockwell D-541-4 “Surprise Fighter” from 1973, an early stealth concept designed to sneak up on Soviet AWACS planes.

Download for $3




Download all seven for $18.90 (10% off)



 Posted by at 1:36 pm
Dec 072015


USLP 03

Issue 03 of US Launch Vehicle Projects is now available (see HERE for the entire series). Issue #03 includes:

  • Juno V/Titan/Nomad: A 1958 concept for a space launcher using an ICBM for upper stages
  • Convair ATE Nova: A 1963 idea for winged airbreathing boosters
  • B-70/Gemini: Using a bomber as a booster
  • Phase II VTOHL Orbit-On-Demand: a 1985 concept for a relatively small two stage to orbit spaceplane
  • NASA Lewis Saturn Ib/Centaur/Kick Stage: a high energy upper stage
  • NASA MSC 042B/Titan IIIL6: a straight-winged orbiter atop a large Titan derivative
  • Heavy Lift Titan: A large diameter Titan core with three Shuttle boosters
  • Escher “Unshackled”: An unconventional idea for a lunar rocket

uslp03ad2 uslp03ad1

USLP #03 can be downloaded as a PDF file for only $4:

——–

—–

Large format USBP drawings, Issues 10-12

The CAD drawings created for USBP reformatted and rescaled for 11X17 collected in a separate volume. Drawings have in some cases been corrected, improved and added to.

USBP 11X17 10-12 collects the diagrams created for issues 10, 11 and 12, including:

Boeing Model 464-34-3, Republic mach 7, Lockheed CL-1301-1, Convair WS-125A, Boeing 484-415, Martin Model 223-10, Boeing Model 814-1010 Dyna Soar, Martin Model 192-5, Boeing Model 464-40, Boeing Model 701-218, Northrop Nuclear flying wing, North American D118, Martin Model 223-11, North American Model 705-00-04, Bell/Martin 464L, Boeing B-1, Boeing Big Bird BB 6800, Boeing Model464-41, Douglas MX-2091-E, Boeing Model 701-238, Martin Model 223-12, Northrop Nuclear Flying Wing, Rockwell MRCC, Lockheed CL-820-8

usbp11x17_10-12ad1

USBP11x17-10-12 can be downloaded as a PDF file for only $10:
————–

—-

Large format USBP drawings, Issues 13-15

The CAD drawings created for USBP reformatted and rescaled for 11X17 collected in a separate volume. Drawings have in some cases been corrected, improved and added to.

USBP 11X17 13-15 collects the diagrams created for issues 10, 11 and 12, including:

Ryan Model 162, Boeing Orbital bomb, Northrop Atomic Wing, Consolidated Vultee High Speed Flying Boat, Martin Model 189, Boeing Model 464-046, Curtis F-87C, Boeing Model 701-247, Lockheed WS 464L Dyna Soar, McDonnell WS 464L Dyna Soar, North American WS 464L Dyna Soar, Republic WS 464L Dyna Soar, Convair WS 464L Dyna Soar I, Convair WS 464L Dyna Soar II, Douglas WS 464L Dyna Soar, Northrop N206 WS 464L Dyna Soar, Boeing Model 814-1010 Dyna Soar II, Bell/Martin WS 464L Dyna Soar, Boeing Model 2050E Dyan Soar, Boeing Dyna Soar/ Titan IIIc, Bell D2001 TS-149, Lockheed Harvey; Convair Model 35, Rockwell D661-27, Boeing Model 464-49, Boeing Model 988-123, Boeing Manned Orbital Bomber, Boeing Model 701-251

usbp11x17_13-15ad1

USBP11x17-13-15 can be downloaded as a PDF file for only $10:
————–

—-

 Posted by at 3:30 pm
