Apr 292018


Artwork was created for USBP 21 by Rob Parthoens depicting the Convair Submersible Nuclear Ramjet paying a visit to 1970’s-era Moscow. If you think that this looks like Project Pluto, you’re not far off; this was also a Mach 4, treetop-level nuclear ramjet powered bomber. But there were a few minor differences. Notice that little bump above the nose? That’s the cockpit, a necessary addition because this design was manned. It was also designed to operate as a submarine, cruising the oceans of the world faster than 100 knots before launching upwards and taking flight. Because the 1950’s were rather more optimistic when it came to technological advancement.

Be sure to check out US Bomber Projects issue 21 to read more about this design.

 Posted by at 8:13 pm
Apr 292018


Rewards have been issued to APR Patreon patrons for April, 2018. This month, the “Diagram” is a Sikorsky lithograph of a Heavy Lift Helicopter concept. The Documents include a US Army catalog of airborne weaponry; a paper describing possible additional missions for the Saturn launch vehicles, and  BOAC brochure extolling the virtues of the Comet 4 jetliner. The CAD diagram is of the British Interplanetary Society’s “Deadalus” starship design.



If you are interested in helping to preserve (and get copies of) this sort of thing, consider signing up for the APR Patreon.



patreon-200

 Posted by at 3:02 pm
Apr 262018


US Bomber Projects #21 and Spacecraft Projects #05 are now available.

US Bomber Projects #21

Cover art was provided by Rob Parthoens, www.baroba.be

US Bomber Projects #21 is now available (see HERE for the entire series). Issue #21 includes:

  • Convair Submersible Nuclear Ramjet: a Mach 4 manned nuclear powered flying submarine
  • Bell MX-776: an early post-war pilotless airplane
  • Convair Manned Flyback Atlas: an unconventional recoverable ICBM
  • DTNSRDC PAR-WIG Strategic Deterrent: a low-flying aircraft packing 4 Trident ballistic missiles
  • Boeing Model 464-197: a supersonic B-52
  • Martin Model 151-K: a pre-war twin-engined medium bomber
  • Boeing Cruise Ballistic Missile: an entire aircraft packed into a silo, carrying an ICBM
  • MC-747 Air Mobile System: a 1973 concept for carrying up to seven ICBMs in a modified cargo jet





USBP #21 can be downloaded as a PDF file for only $4.25:

——–


US Spacecraft Projects #5

US Spacecraft Projects #05 is now available (see HERE for the entire series). Issue #05 includes:

  • Project HORIZON Lunar Lander: a late 1950’s US Army concept for a manned Lunar lander
  • Lockheed-Martin Mars Ascent/Descent Vehicle: A very recent concept for a future manned Mars vehicle
  • JPL Interstellar Precursor: a 970’s design for a space probe to interstellar space
  • Lockheed Modular Rotating Space Station: a truly gigantic design circa 1970
  • Lockheed Payload Carrier: an early 1960’s spaceplane for space station logistics
  • Martin-Marietta Winged NIMF: a nuclear powered “hopper”
  • Lockheed CL-414: a capsule for Man in Space Soonest
  • NASA HAVOC: High Altitude Venus Operational Concept, a 2015 project for manned exploration of the atmosphere of Venus

USSP #05 can be downloaded as a PDF file for only $5.25:

——–




The previous releases of US Aerospace Projects:

US VTOL Projects #2

  • SOS Interceptor: A US Navy Mach 3 aircraft with jettisonable wings
  • Lockheed GL-224-3: A small battlefield surveillance and ground attack plane
  • Phalanx Dragon MP-18: An unconventional  small civilian transport
  • Lockheed L-161-1: An early concept for a variable geometry roadable helicopter
  • GE Supersonic V/STOL: A supersonic strike fighter with flip-out lift fans
  • Convair ANP-VTOL: A nuclear-powered ground-effect craft of the Navy of unusual configuration
  • Piasecki 16H-3: A compound helicopter for high speed passenger transport
  • Boeing Vertol Model 147: A tilt-wing close support fire support design for the US Army

USVP #2 can be downloaded as a PDF file for only $4.25:

——–




US Research & Recon Projects #2

  • Lockheed A-1: The first true design leading to the SR-71
  • Bell MX-2147 Model 105: The high altitude “X-16”
  • Boeing/CRC/AMROC X-34 Reference Configuration: A reusable launcher test vehicle
  • Martin Model 159: A scout/observation float plane
  • NASA-Langley Low-Boom Demonstrator: a recent design to demonstrate quiet SST tech
  • McDonnell-Douglas DC-9 Super 80 Propfan Configuration 1: A fuel efficient transport demo
  • Convair “HAZEL” MC-10: An inflatable Mach 3 plane for the Navy
  • Republic Manned Hypersonic Reconnaissance Vehicle: an early scramjet concept



USRP #2 can be downloaded as a PDF file for only $4.25:

——–



 Posted by at 10:40 pm
Apr 212018


APR Patrons contributing more than $10 per month were today sent a 1969 diagram of a preliminary design for what would become the AWACS plane… close, but with eight engines rather than four. This design was illustrated in color artwork from time to time.

And for APR Patrons at the $4 and above level, a diagram of the 777 and scans of a McDonnell-Douglas brochure on the “Med-Lite Family” of launch vehicle concepts have been uploaded to the 2018-04 APR Extras folder on Dropbox:

If you are interested in these and a great many other “extras” and monthly aerospace history rewards, please sign up for the APR Patreon. What else are you going to spend $4 a month on? Taxes?

patreon-200

 Posted by at 8:42 am
Apr 192018


For the APR Patreon I try to acquire as much interesting aerospace documentation as I can, and these items fall into two categories:

  1. Stuff that I can afford. This stuff winds up in the APR Patreon catalog of potential monthly rewards for patrons.
  2. Stuff I can’t hope to afford.

There’s a lot of the latter category of stuff. Sometimes it’s because the item has a ridiculously high Buy It Now price or starting bid, or because the item will be popular among bidders, or because it’s *really* good/big and thus worth every penny. But unaffordable is unaffordable.

However, there is an option for “stuff I can’t afford:” crowdfunding. I’ve done this a number of times with considerable success, and I’ve just done so again, winning a trio of General Dynamics documents describing a 1965 program to develop a logistics system for extending the Apollo lunar exploration program:

This set of documents was just much too expensive for an individual (well, I’m sure Jeff Bezos or Elon Musk wouldn’t have flinched), but with a group of like-mined funders it came in at $30 per person. So what happens now:

1: I wait for it to show up in the mail.

2: I make a complete set of scans in 300 DPI grayscale (and color, where appropriate) and convert to PDFs

3: I make the scans and PDFs available to funders, generally via Dropbox

4: I find an appropriate archive for the documents, and then donate the originals to them.

5: And that’s it. The files are shared with the funders, but do not appear on future APR Patreon catalogs or as purchasable, downloadable “Diagrams and Documents.” What the funders choose to do with their scans & PDFs is up to them.

APR Patrons get alerted to each of these occasional “crowdfunding opportunities.” So if you’d like to participate, please considered signing up for the APR Patreon.

patreon-200

 Posted by at 12:09 pm
Apr 112018


Some old-school animation showing the AH-56 as a recon and targeting vehicle being used in Someplace Much Like Viet Nam. If you’re at all like me, you’ll watch this and think, “I don’t recall this episode of Jonny Quest.”



 Posted by at 2:10 pm
