Apr 152017


Now available: two new US Aerospace Projects issues:

US Transport Projects #07

US Transport Projects #07 is now available (see HERE for the entire series). Issue #07 includes:

  • Lockheed L-279-9: an early SST
  • Convair HST – Phase II Variable Sweep Configuration: A mid-1960’s hypersonic transport
  • Lockheed CL-1373: a short-haul turboprop liner
  • Boeing Model 702-134(4): a large nuclear-powered logistics hauler
  • McDonnell-Douglas Swept Wing Spanloader: a heavy cargo carrier
  • Lockheed Hybrid Wing Body: a current design for an efficient military transport
  • NASA Cut-Down 747 SCA: a 1973 idea for a Shuttle Carrier Aircraft
  • Rockwell Boost Glide Transport: An early 1970’s rocket transport



USTP #07 can be downloaded as a PDF file for only $4:

——–


Also available, the first in a new series:

US Recon and Research Projects #01

US Recon & Research Projects #01 is now available (see HERE for the entire series). Issue #01 includes:

  • General Dynamics “FISH”: 1958 concept for Mach 4 parasite
  • NACA-Langley X-Tail X-15: early hypersonic rocket plane concept
  • “Jake’s Jeep”: WWII-era motorjet design
  • Lockheed “Archangel”: The first step on the road to the SR-71
  • Boeing Model 853-21 “Quiet Bird”: A 1961 stealth platform
  • Northrop Tacit Blue: Operational version of the early stealth experiment
  • Convair Pilotless Airplane I-40 Inhabited: WWII-era design of a manned test for a flying bomb
  • Lockheed CL-278-1-1: a proto-U-2



USRP #01 can be downloaded as a PDF file for only $4:

——–

——

 Posted by at 11:43 am
Apr 122017


So very, very close on the next two US Aerospace Projects issues. I’m only lacking cover “art”and have to deal with a bit of “dead air” in the middle of US Transport Projects #7. Usually I can shuffle things around well enough to not have this sort of thing, but this time it just hasn’t worked out. I suppose it doesn’t really matter all that much, but it does look kinda lazy like that.

It’s been about a year since I released the last USxP issue. That last issue was the first time where I used vector diagrams embedded within the issue, rather than raster images; getting the diagrams from AutoCAD into Word was a bit of a chore back then. And in the intervening months… I forgot how I did it. So I had to figure it out again, and the process is different. I have to walk the AutoCAD diagram through Rhino 3D and save as a WMF and blah, blah, blah; end result is it works just fine. I’ve done some further refinement… the main outlines are set at 0.25 mm width and the ends of the lines have been reset to rounded and mitered, so sharp corners now look more like sharp corners.

Hoping to have these two out in a day or two. The other three will be rather longer.



 Posted by at 6:57 pm
Apr 022017


I’m essentially done with the drafting portion of the exercise. Now to finish the writing. I had planned on releasing ll five at once, but due to external factors I’ll almost certainly have to split this up. So… which ones do people want more? The publications forthcoming are Fighters, Bombers, Transports, Launchers and Recon & Research. Comment below…

 Posted by at 11:05 pm
Mar 102017


Coming soonish: the return of USXP publications. Five are under current development and are mostly done. There is a new title in the bunch… USRP. Strictly speaking it should probably be USR&RP… United States Research and Recon Projects. Perhaps Recon and Research aren’t necessarily the most obvious categories to link together into a single title, but apart from the vitally important alliteration, there is this important fact: compared to, say, Bombers, there aren’t that many Recon and Research projects out there.

If there are specific proposals, or general categories you’d like to see in future publications, feel free to comment below.

 Posted by at 10:41 am
May 302016


I’ve recently figured out how to get reliably good-quality vector graphic PDF files from my AutoCAD diagrams.These differ from standard “raster” graphics like GIFs and JPGs in that they are composed of scalable lines rather than pixels; this means that they can be printed off at many scales and they’ll retain clarity.

I think a lot of the diagrams would look quite good printed in large format; I’ve previously mentioned that I’m working on a few diagrams specifically for printing off on large format (24X36) mylar, but I’ve others that I think would also look good scaled for 18X24. I’m making these first seven diagrams available, formatted and scaled for 18X24. They can be viewed on screen, printed on a standard printer or printed by a large format printer all with equal clarity.

If this idea appeals, be sure to tell your friends, family, foes, anyone you think might be interested. Also be sure to comment if there are any diagrams I’ve previously created for APR, USXP or elsewhere that you’d like to see in this format. Some of them would be best as multi-sheet diagrams. Suggestions on how to improve also appreciated.

CAD007

CAD 007: Northrop Low Altitude Penetrator

A 1/72 diagram of a 1979 design for a B-2 alternate configuration

Download for $3

———————————

CAD006

CAD 006

A 1/96 scale diagram of the 1979 Rockwell D645-4a spanloader bomber.

Download for $3

———————————

CAD005

CAD 005

A 1/144 scale diagram of the Manned Spacecraft Center MSC Orbiter 020, a 1972 Space Shuttle concept with a single 260″ solid rocket booster.

Download for $3

———————————

CAD004

CAD 004

A 1/350 scale diagram of the 1971 Boeing Resource Air Carrier (AKA RC-1, AKA “Brute Lifter”) designed as a flying oil tanker for the arctic.

Download for $3

———————————

CAD003

CAD 003

A 1/72 scale diagram of the Martin-Marietta “Zenith Star” experimental space-based laser for the Strategic Defense Initiative.

Download for $3

———————————

CAD002

CAD 002

A 1/24 diagram of the Lockheed “Harvey,” the initial concept for a low radar cross section strike platform that eventually became the F-117.

Download for $3

———————————

CAD001

CAD 001

A 1/32 diagram of the North American Rockwell D-541-4 “Surprise Fighter” from 1973, an early stealth concept designed to sneak up on Soviet AWACS planes.

Download for $3




Download all seven for $18.90 (10% off)



 Posted by at 1:36 pm
May 012016


I admit that the USBP series looks kinda… bland. It’s text and line drawings; not a whole lot can be done to jazz that up. Especially since I have no head for graphics design whatsoever apart from layout diagrams.

Still, one reader sent me a mockup of a revised cover of USBP #18:

USBP18blue

Things are moved around a little bit, but the obvious change is the addition of color. The suggestion was also made to consider color-coding each title in the USXP series. Just off the top of my head, I came up with:

Bombers: Olive Drab

Spacecraft: Black

Launch Vehicles: Blue on bottom, transitioning to black at the top

Fighters: slightly bluish gray (like the F-15 or F-22)

Transports: ??

VTOL: ??

The USBP#18 cover was re-done to reflect this, thusly:

USBP18green

Thoughts? Is this more appealing?How about color-coding… good idea or not? And if so, what colors?

I tried something vaguely like this once before, with USBP#05.

 Posted by at 10:41 am
Apr 172016


Now available: two new US Aerospace Projects titles.

US Bomber Projects #18

US Bomber Projects #18 is now available (see HERE for the entire series). Issue #18 includes:

  • Boeing Model 726-13: A nuclear pwoered bomber with the cockpit in the tail
  • Martin Model 164: A pre-war high altitude twin-tailed bomber
  • North American WS-110A: An early concept for what became the B-70, with “floating wingtips”
  • Convair MX-1593: An Early, large five-engined Atlas ICBM concept
  • Boeing Model 701-299-1: The final XB-59 supersonic bomber design
  • Boeing Model 464-72: A B-52 with pusher turboprops
  • Boeing F-15GSE Global Strike Eagle: An unmanned F-15 with a giant missile on its back General Dynamics – Light Weight Attack Configuration 29: An advanced ground attacker with vectored thrust

usbp18ad2 usbp18ad1

USBP #18 can be downloaded as a PDF file for only $4:

——–

——

US Transport Projects #6

US Transport Projects #06 is now available (see HERE for the entire series). Issue #06 includes:

  • Lockheed CL-408-15: An early Mach 3 SST
  • Lockheed L-155-4: A very early 8-engine jetliner
  • Boeing Model 754-4V: A very-wide-bodied cargo hauler for Husky
  • Gates Learjet PD1502A: A four-seater with a turbofan
  • Convair Comet Seaplane: An American idea for turning a British jetliner into Flying Boat
  • Lockheed Twin C-5 Shuttle Carrier Aircraft: Two C-5’s mated together to carry a Shuttle between them
  • Boeing Model 765-096 Rev A “SUGAR Volt”: A hybrid jetliner
  • CRC HOT EAGLE – Super Global Troop Transport: Finally, hard data on a rocket transport for Special Forces and Marines

ustp06ad2 ustp06ad1

USTP #06 can be downloaded as a PDF file for only $4:

——–

——

And don’t forget…

US Fighter Projects #1 and US VTOL Projects #1 are still new and still available!

 Posted by at 10:42 pm
Jan 232016


USSP #04

US Spacecraft Projects #04, the Lander Special is now available (see HERE for the entire series). Issue #04 includes:

  • GE Electrically Propelled Cargo Vehicle: A lunar lander with a nuclear reactor and ion engines to reduce the cost of lunar logistics
  • Douglas LASS: Landing an S-IVb stage on the moon
  • Convair PLAME: VTOL crew return with jet engines
  • North American Mars Excursion Module: the iconic conical Mars lander
  • Martin-Marietta Ballistic NIMF: A nuclear “hopper”
  • Early LEM: One of the first recognizable designs, by Maxime Faget
  • ROMBUS: probably the largest lunar lander seriously proposed
  • Boeing Lander Module 2: A recent Mars crew lander

ussp04ad1 ussp04ad2

USSP #04 can be downloaded as a PDF file for only $5:

——–

—–

USTP #05

US Transport Projects #05 is now available (see HERE for the entire series). Issue #05 includes:

  • Boeing Model 820-100: The B-52 can haul more than bombs…
  • Lockheed Nuclear Tug: Want to tow two C-5s across an ocean?
  • Martin Super Ocean Transport: A WWII-era design for a post-war giant passenger transport
  • HOT EAGLE: 13 Marines to Benghazi in minutes
  • Sikorsky SST: An early supersonic transport concept
  • Lifting Body Cargo Airplane: A wartime design for a multibody design with a separate cargo module
  • Resource Air Carrier: A giant “flying pipeline” to haul petroleum
  • Boeing Model 763-165: A side-by-side New Large Airplane design

ustp05ad2 ustp05ad1

USTP #05 can be downloaded as a PDF file for only $4:

——–

—–

AND don’t forget these…



USLP 03

Issue 03 of US Launch Vehicle Projects includes:

  • Juno V/Titan/Nomad: A 1958 concept for a space launcher using an ICBM for upper stages
  • Convair ATE Nova: A 1963 idea for winged airbreathing boosters
  • B-70/Gemini: Using a bomber as a booster
  • Phase II VTOHL Orbit-On-Demand: a 1985 concept for a relatively small two stage to orbit spaceplane
  • NASA Lewis Saturn Ib/Centaur/Kick Stage: a high energy upper stage
  • NASA MSC 042B/Titan IIIL6: a straight-winged orbiter atop a large Titan derivative
  • Heavy Lift Titan: A large diameter Titan core with three Shuttle boosters
  • Escher “Unshackled”: An unconventional idea for a lunar rocket

uslp03ad2 uslp03ad1

USLP #03 can be downloaded as a PDF file for only $4:

——–

—–

Large format USBP drawings, Issues 10-12

The CAD drawings created for USBP reformatted and rescaled for 11X17 collected in a separate volume. Drawings have in some cases been corrected, improved and added to.

USBP 11X17 10-12 collects the diagrams created for issues 10, 11 and 12, including:

Boeing Model 464-34-3, Republic mach 7, Lockheed CL-1301-1, Convair WS-125A, Boeing 484-415, Martin Model 223-10, Boeing Model 814-1010 Dyna Soar, Martin Model 192-5, Boeing Model 464-40, Boeing Model 701-218, Northrop Nuclear flying wing, North American D118, Martin Model 223-11, North American Model 705-00-04, Bell/Martin 464L, Boeing B-1, Boeing Big Bird BB 6800, Boeing Model464-41, Douglas MX-2091-E, Boeing Model 701-238, Martin Model 223-12, Northrop Nuclear Flying Wing, Rockwell MRCC, Lockheed CL-820-8

usbp11x17_10-12ad1

USBP11x17-10-12 can be downloaded as a PDF file for only $10:
————–

—-

Large format USBP drawings, Issues 13-15

The CAD drawings created for USBP reformatted and rescaled for 11X17 collected in a separate volume. Drawings have in some cases been corrected, improved and added to.

USBP 11X17 13-15 collects the diagrams created for issues 10, 11 and 12, including:

Ryan Model 162, Boeing Orbital bomb, Northrop Atomic Wing, Consolidated Vultee High Speed Flying Boat, Martin Model 189, Boeing Model 464-046, Curtis F-87C, Boeing Model 701-247, Lockheed WS 464L Dyna Soar, McDonnell WS 464L Dyna Soar, North American WS 464L Dyna Soar, Republic WS 464L Dyna Soar, Convair WS 464L Dyna Soar I, Convair WS 464L Dyna Soar II, Douglas WS 464L Dyna Soar, Northrop N206 WS 464L Dyna Soar, Boeing Model 814-1010 Dyna Soar II, Bell/Martin WS 464L Dyna Soar, Boeing Model 2050E Dyan Soar, Boeing Dyna Soar/ Titan IIIc, Bell D2001 TS-149, Lockheed Harvey; Convair Model 35, Rockwell D661-27, Boeing Model 464-49, Boeing Model 988-123, Boeing Manned Orbital Bomber, Boeing Model 701-251

usbp11x17_13-15ad1

USBP11x17-13-15 can be downloaded as a PDF file for only $10:
————–

—-

 Posted by at 8:27 pm
Jul 082015


Now available… three new additions to the US Aerospace Projects series.

US Bomber Projects #15

USBP#15 includes:

  • Bell D2001: A 1957 eight-engined Bell VTOL strike plane for the Navy
  • Lockheed “Harvey”: AKA the Hopeless Diamond, Lockheeds first design for what became the F-117
  • Convair Model 35: An early push-pull concept for the B-36
  • Rockwell D661-27: A nuclear powered strategic bomber
  • Boeing Model 464-49: The penultimate major design in the development of the B-52
  • Boeing Model 988-123: A highly agile stealthy strike fighter
  • Boeing Orbital Bomber: An early concept for a Dyna Soar derivative with eight nukes
  • Boeing Model 701-251: A twin engined concept on the road to the XB-59

USBP#15 can be purchased for downloading for the low, low price of $4.

usbp15ad2

usbp15ad1

——————————————-

US Transport Projects #4

USTP#4 includes:

  • Boeing Model 473-13: An early twin-engine jetliner
  • ICARUS Troop Transport: 1,200 marines, anywhere, anytime
  • Republic Model 10 SST: A little known SST competitor
  • Lockheed CL-593: A giant, if slow, logistics transporter
  • Boeing 763-059 NLA: A whole lotta passengers in one place
  • Fairchild M-534: A B-36 converted into a vast cargo carrier
  • Lockheed CL-1201: Probably the largest aircraft ever designed
  • Oblique All-Wing Supersonic Airplane: A supersonic variable-orientation flying wing

USTP#4 can be purchased for downloading for the low, low price of $4.

ustp04ad2

ustp04ad1

——————————

US Launch Vehicle Projects #2

USLP#2 includes:

  • Juno V, 4 stage: An early design that became the Saturn rocket
  • Boeing “Space Freighter”: a giant two-stage spaceplane for launching solar power satellites
  • Boeing NASP-D: A rare look at an operational National Aerospace Plane derivative
  • LLNL Mockingbird: The smallest SSTO ever designed
  • Boeing Model 922-101: A fully reusable Saturn V
  • NAR Phase B Space Shuttle: a fully reusable two-stage concept
  • Martin Marietta Inline SDV: A Shuttle-derived heavy lifter
  • Scaled Composites Model 351: The Stratolaunch carrier aircraft

USLP#2 can be purchased for downloading for the low, low price of $4.

uslp02ad2

uslp02ad1

 Posted by at 12:41 am
Apr 062015


Now available… two new additions to the US Aerospace Projects series.

US Bomber Projects #14: System 464L Special

USBP#14 brings together the competitors to Weapon System 464L, the first major effort in the Dyna Soar program. These designs were previously shown individually in prior issues of USBP; here they are brought together, with some updates, as well as a few extra diagrams and a section of diagrams formatted for 11X17 printing. This issue includes info and diagrams of the Lockheed, Republic, General Dynamics, McDonnell, Boeing, Douglas, Northrop, North American and Martin-Bell entries as well as their various booster systems. Also included are detailed diagrams of the ultimate Dyna Soar design, the 2050E.

USBP#14 can be purchased for downloading for the low, low price of $6.

usbp14ad2

usbp14ad1



 Also available:US Transport Projects #03.

Included in this issue:

  • Lockheed “Environmentally Responsible Aviation” box-wing jetliner
  • Martin Commercial Twin-Hull concept from 1942
  • North American Aviation NAC-60 SST competitor
  • McDonnell-Douglas Cargo Spanloader
  • Boeing Model 763-058 “New Large Airplane”
  • BoMi Passenger Transport Rocket
  • Lockheed L-152-1 early jet transport with unusual inlets
  • Aerial Relay System: for when crazy is preferred

USTP #03 can be purchased for download for only $4:



ustp03ad2

ustp03ad1

 Posted by at 3:43 am
